Specifications:
Power Output:180 watts RMS
Speaker Configuration: 15" BlueLine speaker
High Input:Impedance 3.9MOhms / Input range 150mV - 20V p-p
Low Input:Impedance 10KOhms / Input range 300mV - 40V p-p
Line Input:Impedance 22kOhms / Input level 0dBu nominal
Effects Return:Impedance 22kOhms / Level 0dBu nominal
Tuner Output:Impedance 22kOhms / Level 0dBu nominal
Effects Send:Impedance 22kOhms / Level 0dBu nominal
DI Output:600 Ohms balanced / Level -20dBu nominal
Speaker Outputs:Minimum impedance 4 Ohms
Bass:+/-15dB @ 100Hz
Lo Mid:+/-15dB @ 220Hz
Middle:+/-15dB @ 660Hz
Hi Mid:+/-15dB @ 1.6kHz
Treble:+/-15dB @ 7kHz shelving
Deep:+8dB @ 50Hz
Bright:+10dB @ 10kHz
Signal to Noise:Better than 80dB (EQ flat)
Distortion:Less than 0.5% THD
Frequency Response:-3dB at 33Hz and 25KHz
Power Requirements:230 /115v
H x W x D (mm):693 x 485 x 665
Weight (kg):25kg
